Product gallery · 5POF Polyolefin Thermal (heat)Shrinkable Cling Film
Product code:APIG-290
H.S. code:3920620000
Wholesale price:$3.25 /only
Category:POF Shrink Film (Polyolefin)
Technical Documents:
📥1 Asia Pacific -Technical Specification For Shrinking Film 01-Compressed.pdf📥2 Asia Pacific -Technical Specification For Shrinking Film 02-Compressed.pdf📥3 Asia Pacific -Polyolefin Film TDS-Compressed.pdf📥4 Asia Pacific -Polyolefin Film-FDA-Compressed.pdf📥5 Asia Pacific -Polyolefin Film-SGS-Compressed.pdf📥6 Asia Pacific -Polyolefin Film-ROHS--Compressed.pdf📥7 Asia Pacific -MSDS-POF-Compressed.pdfEnvironmentally-friendly packaging film -POF Polyolefin Thermal (heat)Shrinkable Cling Film
Types:
1.) POF cling shink film -Center Folded (such as: 19mic x 45cm x 1000Mtr,30 mic x 585 mm x 1500 m)
2.) POF cling shink film - Tubular Form (such as: 25 mic x 330 mm x 1000 m)
2.) POF cling shink film - Tubular Form (such as: 25 mic x 330 mm x 1000 m)
3.)POF macro perforated cling film
Thickness :12-25 microns
Test report of the POF cling film for reference :
Property 性能 | Unit 单位 | Test Method 测试方法 | Representative Value 代表数值 | ||
Thickness 厚度 | Micron | 15 | 19 | 25 | |
Density 密度 | g/cm³ | 0.920 | 0.920 | 0.920 | |
Yield 产量 | ㎡/kg | 72.5 | 57.2 | 43.5 | |
Tensile propeiries 拉伸性能 | |||||
Elastic Modulus 坚韧度 | N/mm² | ASTM-D882A | MD/TD | MD/TD | MD/TD |
340/350 | 340/340 | 360/450 | |||
Tensile Strength 拉伸强度 | N/mm² | ASTM-D882 | 110/110 | 110/110 | 100/100 |
% | ASTM-D882 | 110/110 | 110/110 | 105/105 | |
Elongation@ break 拉伸极限 | |||||
Seal Strength | g/cm³ | Internal | 870 | 1025 | 1250 |
封口强度 | N/mm² | 57 | 53 | 49 | |
Tear Propagation 抗撕裂强度 | g/cm³ | 5.5 | 9.5 | 14.5 | |
COF.film to film.Kinetic 摩擦系数极限 | adim. | ASTM-D1894 | 0.26 | 0.25 | 0.24 |
Free Shrink@125℃-140℃收缩率 | % | ASTM-D2732 | MD/TD 65/65 | MD/TD 62/62 | MD/TD 60/60 |
Optical Properties 光学性能 | % | ASTM-D1003 | 1.3 | 1.8 | 3.0 |
Haze 雾度 | photoc | ASTM-D2457 | 135 | 135 | 130 |
Gloss 光泽度 | |||||
Specification of products | |||||
thickness | 15 µ m | 19 µ m | 25 µ m | ||
width | 100mm-1500mm | 100mm-1500mm | 100mm-1500mm | ||
length of roll | single | 8750ft | 7000ft | 5250ft | |
center fold | 4370ft | 3500ft | 2185ft | ||
( English ) | |||||
Thickness | 15 µ m | 19 µ m | 25 µ m | ||
Width | 100mm-1500mm | 100mm-1500mm | 100mm-1500mm | ||
Length | single wound | 8750ft | 7000ft | 5250ft | |
per roll | center fold | 4370ft | 3500ft | 2185ft | polyolefin |
