Single side Heat Sealable BOPP film
APPLICATION
Is intended to be used as the outer layer of
HFFS and VFFS complexages for applications. it
gives a premium look when printed reverse.
The matte side is designed for heat sealing and
not suitable for cold sealing. The matte side is
sealable all internal surfaces which are Manucor
sealable
Key Features
• uniform matte appearance without
optical defects
• Low brightness and opacity of the face
matte
• Slip consistent and low for a
good behavior Machine
• Smooth surface, satiny appearance paper
• Excellent flatness without undulations
Single side Heat Sealable BOPP film
SpecificationsThickness | 18 microns/ 20 microns. Gauge variation +/- 1% |
Density | 0.91 gram/cm3 |
Weight | 16.38 g/m2 for 18 micron, 18.20 g/m2 for 20 micron. Variation +/- 1% |
Yield | 61.05 m2/kg for 18 micron, 54.95 m2/kg for 20 micron |
Tensile strength | Not less than 130 N/mm2 (MD), 230(TD) |
Elongation at break | Not more than 220% (MD), 80%(UD) |
Thermal shrinkage | At 1200c, 5min, not more than 5%(MD), 3%(TD) |
Heat sealing strength | A 1300c, 1 bar, 1 sec, N/15 mm – 2.2 to 2.3 |
Haze | Not more than 2.5% |
Gloss | At 450, Not less than 85% |
Heat sealing Range | At 1 bar, I sec – 1050 to 1400 |
Treatment level | Not less than 38 Dyne/cm on one side of film |
