Product gallery · 5BOPP PEARLIZED FILM(BOPP WHITE OPAQUE FILM)
Product code:APIG-243
H.S. code:3920620000
Wholesale price:$3.25 /only
Category:BOPP Film (Polypropylene film)
Technical Documents:
📥1 Asia Pacific- BOPP Pearl Film,Technology Data 25 38 40 Mic-Compressed.pdf📥2 Asia Pacific- BOPP Pearl Technology Data2 -Compressed.pdf📥3 Asia Pacific- BOPP Co-Ex Pearlized Opaque Film Technology Data3-Compressed.pdf📥4 Asia Pacific- BOPP Pearl -38Micron Specification Buyer's Requirement-Compressed.pdf📥5 Asia Pacific- BOPP Pearl - MSDS-Compressed.pdfBOPP PEARLIZED FILM(BOPP WHITE OPAQUE FILM)
Is widely used for packaging application’s in surface printing . with both sides heat sealable. the film shows the pearlized white opacity appearance.
Thickness : 18,20,24,25,30,35,40,45 UM (microns)
Color : Silver whiteness with glossy pearl
Character: high heat strength ; excellent ultraviolet resistance ; excellent prarlized
Appearance ; high separative function
Applications: used for food ,chopsticksand ,gift ,soap package and freeze cold drink such as ice cream .thermal label ,sweet food ,biscuit ,snack food. As well can laminating with CPP or PE film .
| Tech data for reference : | ||||||||
| TYPICAL PROPERTIES | UNIT | TEST METHODS | TYPICAL VALUE | |||||
| THICKNESS | micron | Micrometer | 25 | |||||
| YIELD | m2/kg (min.) | - | 59 | 49 | 42 | 35 | 28 | |
| DENSITY | g/cm3 | ASTM D-1505 | 0.65-0.70 | 0.65-0.70 | 0.65-0.70 | 0.68-0.72 | 0.68-0.72 | |
| TENSILE STRENGTH | kg/mm2 | MD | ASTM | 6 | 6 | 6 | 6 | 6 |
| (min.) | TD | D-882 | 12 | 12 | 12 | 12 | 12 | |
| ELONGATION AT BREAK | % | MD | ASTM | 140 | 140 | 140 | 140 | 140 |
| (max.) | TD | D-882 | 50 | 50 | 50 | 50 | 50 | |
| THERMAL SHRINKAGE | % | MD | ASTM | 4 | 4 | 4 | 4 | 4 |
| (120° c 15 minutes) | (max.) | TD | D-1204 | 2 | 2 | 2 | 4 | 4 |
| STATIC C.O.F. | film/film | ASTM D-1894 | 0.3 - 0.4 | 0.3 - 0.4 | 0.3 - 0.4 | 0.3 - 0.4 | 0.3 - 0.4 | |
| SEALING TEMPERATURE | °c | 1 BAR 1 SEC | 115 | 115 | 115 | 115 | 115 | |
| SEALING STRENGTH | g/cm (min.) | - | 80 | 80 | 80 | 80 | 80 | |
| GLOSS (angle 45° ) | % (min.) | ASTM | 26 | 26 | 26 | 26 | 26 | |
| D-2457 | ||||||||
| WVTR | g/m2/24 hr (max.) | ASTM F-1249 | 5 | 4.2 | 3.6 | 3.2 | 3 | |
| O2TR | cc/m2/24 hr (max.) | ASTM D-3985 | 1,700 | 1,600 | 1,500 | 1,400 | 1,200 | |
| CORONA TREATMENT | Dyne/cm (min.) | ASTM D-2578 | 38 | 38 | 38 | 38 | 38 |
BOPP pearlized film(BOPP white opaque film）
