BOPET PLAIN FILM

Name: BOPET PLAIN FILM
Brand: Asia Pacific Industry Group
SKU: 257

Product code:APIG-257

H.S. code:3920620000

Wholesale price:$3.25 /only

Category:BOPET Film (Polyester Film)

Check Details Chat Now

Technical Documents:

📥1 Asia pacific -6.0 Mic PET-Compressed.pdf 📥2 Asia Pacific -Technology Data Of 10 12 Mic PET Clear & Metallized-Compressed.pdf 📥3 Asia Pacific -Technology Data Of 12 23 36 ic BOPET -Compressed.pdf 📥4 Asia Pacific -Technology Data Of 100,150,250,350 Mic BOPET-Compressed.pdf 📥5 Asia Pacific -Technical Specification -BOPET 350Mic White 200,250 Mic Clear-Compressed.pdf 📥6 Asia Pacific -12Um BOPET Chemical Coating Film-Compressed.pdf 📥7 Asia Pacific -Vacuum Metallized Polyester Film-Compressed.pdf 📥8 Asia Pacific -150Um BOPET Clear And White-Compressed.pdf 📥9 Asia Pacific -Technology Data Of 50-250Mic BOPET-Compressed.pdf 📥10 Asia Pacific -Polyester Specification -4.5Mic BOPET COA -Compressed.pdf 📥11 Asia Pacific -10,12Microns Thermal Transfer BOPET Film No Corona Treatment-Compressed.pdf 📥12 Asia Pacific -Polyester Film Test Report-Compressed.pdf 📥13 Asia Pacific -Plain BOPET Film-Compressed.pdf 📥14 Asia Pacific -BOPET Heat Shrinkage Film-Compressed.pdf 📥15 Asia Pacific -MSDS 2 Of BOPET-Compressed.pdf 📥16 Asia Pacific -BOPET-FDA,Vcm,重金属,三聚氰胺等四项Heavy Metals, Melamine, Etc. (English)-Compressed.pdf 📥17 Asia Pacific -BOPET-EU,卤素,邻苯二甲酸盐或酯,甲醛,双酚A等五项Eu, Halogen, Phthalate Or Ester, Formaldehyde, Bisphenol A, Etc. (English)-Compressed.pdf

BOPET PLAIN FILM
BOPET film (biaxially oriented Polyester films) featurines good thermal stability and tenacity; low air and water permeability; applicable to vacuum aluminum plating, compound package, cooking bag manufacture, etc.
Featuring :
Having the good adhesion with ink and coating, can be used for multi-color printings with good flatness. Is mainly used in heat-sealing bags of frozen food, industrial products and cosmetics packaging.
Specification:
thickness: 12 microns-25 microns, 75 microns-150 microns ,185 microns-380 microns, 500 microns
width :200-1200MM
length : 500m ,1000m ,1500m,4000m,6000m,9000m,12000m
Polyester film is wound around paper shaft with an internal diameter of 76.2mm-152.4mm and covered with polyethylene film; each coil is supported by damper and put in carton; medium and large package needs wooden mount.
Customer's own requirement is available for us such as printed OEM logos and private label or particular size and package style.

Polyester Film Test Report

Film Item	BOPET	Date	Quantity	2,841tons
Roll NO.	B--07121704	Test Date	Temperature/Humidity Condition	23℃/50RH
Test Criterion	《Polyester testing method》Thickness :14um
No.	Item	Unit	Average	Standard Deviation	Remarks
1	Average Thickness/Thickness Tolerance	ΜM	14.2	0.17	Average Thickness Tolerance: +1.7%
%	Min.: -1.9	Max:+1.9
2	Tensile Strength	MD	Mpa	235	10
TD	268	35
3	Elongation	MD	%	130	13
TD	113	12
4	Heat Shrinkage	MD	%	1.7	0.2	Temperature:150℃ Time:30min
TD	-0.1	0.1
5	Haze	%	2.3	0.1
6	1.2 Glossy	45°
7	COF	ΜS	1.41	0.03	Opposite Surface :F/F
ΜK	1.38	0.01
ΜS	Same Surface :F/F
ΜK
8	Modul	MD	M Pa	4474	122
TD	4914	308
9	Humid Tension	M N/M	58
10	Hot-SealingStrength	N/15mm	1bar/130℃/1s
11	Relative Dielectric Constant（50Hz）
12	Dielectric Dissipation Factor（50Hz）	Pp M
13	Dielectric Strength	V/ΜM
14	Volume Resistivity	ΩCm
15	F 5	MD	108	2.3
TD	97	1.8
Test Dept.: Quality	Value: Excel	Test Person:
Reviewed By
